Industrial robot signal cable with shield | China special cable manufacturer

Спецификация

Basic structure	Conductor+Insulation+Jacket
Conductor	Plain Copper/ Tinned Copper
Insulation	EPR
Braid	Kevlar/ Plain Copper/ Tinned Copper
Jacket	PUR/TPE/PCP

Узнать сейчас Следующий продукт

ВВЕДЕНИЕ

derul robot signal cable application：

It is mainly used for signal connection from the robot base to the control cabinet,in dry or humid rooms,and is used in fixed,vibration and occasional movement situations.The cable is oil-resistant and has excellent EMC shielding effect.

derul robot signal cable structure：

Conductor:Multiple strands of oxygen-free bare copper wire stranded(please specify tinned wire),refer to VDE 0295 class 6/IEC 60228 class 6 standard;

Insulation:special modified PVC/TPE/ETFE;

Insulation marking:Colored wire core markings refer to DIN 47100 standard;

Aggregated structure:Each two cores are twisted in pairs,and then all pairs are re-twisted at an optimized pitch;each layer is specially adjusted and covered with non-woven material;

Shielding layer:high bending resistance tinned copper wire braid,density≥85%;

Outer sheath:PUR,or modified PVC mixture;

Sheath color:black(BK,RAL9005),gray(GY,RAL7001),green(GN,RAL6018);

derul robot signal cable technical parameters

Working voltage:300/300V

Test voltage:1000V

Insulation resistance:20MΩ·km

bending radius

---Occasional movement:10*D

---Fixed installation:4*D

No harmful substances:RoHS

Electromagnetic compatibility:Complies with the Electromagnetic Compatibility Directive(EMC)

Flame retardant properties:refer to VDE 0472-804 Part B test standard,and IEC 60332-1

ПРЕИМУЩЕСТВА

●Highly wear-resistant and oil-resistant PUR robot cable,suitable for bending and torsional movements of dynamic drag chain systems

●The outer diameter of the cable is small,the bending radius is smaller,and the installation space is saved

●Using a strong PUR outer sheath,low-viscosity surface,wear-resistant and scratch-resistant,more durable in harsh environments with mechanical stress

●Oil-resistant,corrosion-resistant,resistant to various lubricants containing mineral oil and other chemical media

●Wide temperature range,flexible at low temperatures,heat-resistant and flame-retardant,suitable for harsh climate environments

●Can be rotated,supports customized rotation±180°/0.5m

●Shielded robot cable,high bending resistance tinned copper mesh shielding layer,with excellent anti-electromagnetic interference performance

●The source factory can design and customize robot cable products with comprehensive functions according to the actual working conditions of customers.The delivery cycle is short and the shipment is fast.

ВОЗМОЖНОСТЬ ПЕРСОНАЛИЗАЦИИ

Whenever standards are not enough!

Considering different working conditions and equipment to be applied to, Derul's products are highly customized. The high customization of our cables can make sure that our products can best meet the demands in your practical application. We welcome you to send an inquiry with specific requirements to our professional sales, and we will provide a technical sheet with drawings of the cable and detailed specifications to you, and of course, a competitive quotation will be send to you soon after your confirmation on the technical sheet. This can lead to your successful and efficient purchasing.

You don't need to worry about the time cost of your customized purchasing. As the original manufacturer, we provide quick-response and "solution at once" services. Comparing to less-efficient communication about technical and quality issues with trading companies, we give our customers efficient feedback to every question raised from them, this is possible because of the close interconnection between our workshop, engineers and sales people.

Часто задаваемые вопросы

Q: Derul Cable является производителем или торговой компанией?

A: Derul Cable - это специальный производитель кабелей, базирующийся в Шанхае.

Q: Является ли цена договорной?

A: Да, цена договорная в зависимости от объема покупки.

Q: Каков стандартный минимальный заказ для кабеля?

A: Любое количество можно приобрести для товара на складе. Для продукции, которая должна быть изготовлена после заказа, минимальный объем заказа обычно составляет 100-200 м на тип.

Q: Как я могу получить образцы?

A: После оплаты потенциальной стоимости, включая экспресс-доставку и подтверждение размеров и структуры кабеля, мы организуем образец и отправим его прямо к вашей двери.

Q: Доступны ли услуги OEM или ODM?

A: Доступны услуги OEM и ODM. Вы можете предоставить нам свое требование, и мы оценим его, чтобы продвинуться вперед.

Q: Каково обычное время производства?

A: Для производства обычного количества обычно требуется около 15-25 дней.
