PUR crane/gantry crane cable (flat cable) - China Derul brand manufacturer and supplier Supplier China

PUR crane/gantry crane cable (flat cable) - China Derul brand manufacturer and supplier

Спецификация

Basic structure	Conductor+Insulation+Jacket
Conductor	Plain Copper/ Tinned Copper
Insulation	EPR
Braid	Kevlar/ Plain Copper/ Tinned Copper
Jacket	PUR/TPE/PCP

Узнать сейчас Следующий продукт

ВВЕДЕНИЕ

Derul crane (gantry crane) flat cable | Application scope:

Deru crane's flat cable and steel wire design are not only suitable for the transmission system of large cranes, but are also widely praised for transportation machinery and pipeline machines. Its unique retracting movement along with the guidance of a towing shaft or similar device allows it to operate in various complex states, whether it is a dry or ventilated indoor environment, an open space in the open air, or even an industrial ventilated environment. response. Moreover, due to its small bending radius, it can be easily installed and used in various space setting environments.

Derul crane (gantry crane) flat cable | technical parameters:

Conductor: Multi-strand finely twisted oxygen-free copper wire conforms to VDE0295 CLASS 5 or 6 standard

Insulation: Special blended PVC soft insulation

Color code: In line with 227IEC+EN50214

Core wire structure: straight arrangement or plum blossom arrangement

Reinforcement: Galvanized soft steel wire (when freely suspended over 80 meters)

or fiber aramid yarn (optional)

Sheath material: special mixed elastic PVC sheath

Sheath color: black (RAL9005) or gray (RAL7001)

Rated voltage: U0/U 450/750V

Test voltage: 2500V

Minimum bending radius:

Fixed installation: 8×D (minimum side of cable)

Mobile installation: 10×D (minimum side of cable)

Operating temperature range:

Fixed installation: -35℃ to +70℃

Mobile installation: -20℃ to +70℃

Radiation resistance: 8×10^7cJ/kg

Flame retardancy: in line with IEC60332-1

Derul crane (gantry crane) flat cable|Specifications:

3*70+1 3*70+2

3*90+1 3*90+2

3*120+1 3*120+2

3*150+1 3*150+2

3*185+1 3*185+2

3*240+1 3*240+2

3*300+1 3*300+2

ПРЕИМУЩЕСТВА

Derul crane flat cables, with steel wire design, are not only suitable for the transmission system of large cranes, but are also widely used in transportation machinery and conveyors. Its unique retracting movement along with the guidance of the towing axle or similar device makes it stable in various complex environments. It adopts a flat design, which can better adapt to the interior of the car than traditional round cables. Small space.

The wire is soft and can fit better through narrow gaps such as vehicle frames and dashboards, making connections easier.

The most important thing is that it is made of high-temperature durable materials and can run for a long time in high-temperature environments without damage.

ВОЗМОЖНОСТЬ ПЕРСОНАЛИЗАЦИИ

Whenever standards are not enough!

Considering different working conditions and equipment to be applied to, Derul's products are highly customized. The high customization of our cables can make sure that our products can best meet the demands in your practical application. We welcome you to send an inquiry with specific requirements to our professional sales, and we will provide a technical sheet with drawings of the cable and detailed specifications to you, and of course, a competitive quotation will be send to you soon after your confirmation on the technical sheet. This can lead to your successful and efficient purchasing.

You don't need to worry about the time cost of your customized purchasing. As the original manufacturer, we provide quick-response and "solution at once" services. Comparing to less-efficient communication about technical and quality issues with trading companies, we give our customers efficient feedback to every question raised from them, this is possible because of the close interconnection between our workshop, engineers and sales people.

Часто задаваемые вопросы

Q: Derul Cable является производителем или торговой компанией?

A: Derul Cable - это специальный производитель кабелей, базирующийся в Шанхае.

Q: Является ли цена договорной?

A: Да, цена договорная в зависимости от объема покупки.

Q: Каков стандартный минимальный заказ для кабеля?

A: Любое количество можно приобрести для товара на складе. Для продукции, которая должна быть изготовлена после заказа, минимальный объем заказа обычно составляет 100-200 м на тип.

Q: Как я могу получить образцы?

A: После оплаты потенциальной стоимости, включая экспресс-доставку и подтверждение размеров и структуры кабеля, мы организуем образец и отправим его прямо к вашей двери.

Q: Доступны ли услуги OEM или ODM?

A: Доступны услуги OEM и ODM. Вы можете предоставить нам свое требование, и мы оценим его, чтобы продвинуться вперед.

Q: Каково обычное время производства?

A: Для производства обычного количества обычно требуется около 15-25 дней.
